เครื่องมือสอบเทียบ

Technical Specifications

Instrument Warranty

Two-year warranty, excluding consumables (sensors, filters, etc.)

Case Material

IP66 - Impact resistant polycarbonate

Dimensions

470 x 180 x 190 mm (16.7” x 7.1” x 7.5”)

Weigh

6.8 kg (15 lbs)

Display

Graphic liquid crystal display with backlight

Sensors

Combustible Gas – Catalytic Diffusion                          Methane, Propane, Butane, Isobutane, LPG, Ethanol, Pentane – Infrared                                                                        Oxygen and Toxic Gases – Electrochemical                     CO2 – Infrared                                                                        Isobutylene – PID

Wireless Network

2.4 GHz - 100 mW - IEEE 802.15.4
30 devices per network
16 independent networks
Communication distance : 0.6 mile line of sight

Datalogging Capacity

200,000 measurements

Operating Temperature Range

-20°C to +50°C (-4°F to 122°F) sensor dependent

Operating Humidity Range

1% to 99% RH sensor dependent

Power Source (Run Time)

NiMH (up to 170 hours operating time, 135 hours in wireless mode)

Recharge Time

4.5 hours, typical
